Windshield Outside Moisture Sensor Replacement

WARNING: This page is about a different car, the 2011 Cadillac DTS. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Outside Moisture Sensor Assembly & Headliner Harness Electrical Connector

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure Remove the vehicle direction alert alarm warning module. Refer to Vehicle Direction Alert Alarm Warning Module Replacement . Slide upward the plastic mirror harness cover. Disconnect the electrical connector at the base of the windshield outside moisture sensor.
1	Headliner Harness Electrical Connector
2	Windshield Outside Moisture Sensor Assembly TIP: Push the sensor upward from the base in order to release from the windshield base.

Callout

Component Name

Preliminary Procedure

Remove the vehicle direction alert alarm warning module. Refer to Vehicle Direction Alert Alarm Warning Module Replacement .
Slide upward the plastic mirror harness cover.
Disconnect the electrical connector at the base of the windshield outside moisture sensor.

Headliner Harness Electrical Connector

Windshield Outside Moisture Sensor Assembly
TIP: Push the sensor upward from the base in order to release from the windshield base.
