Caster Adjustment

NOTE: Rear caster is not adjustable.

At ball joint carrier on lower control arm, loosen nut on bottom of pivot bolt and nut on top of caster eccentric. See Figure and Figure . Rotate caster eccentric until front caster is set to specification. See WHEEL ALIGNMENT SPECIFICATIONS  . Tighten caster eccentric nut and pivot bolt nut to specification. See TORQUE SPECIFICATIONS  .
