System Specifications

Technical Data - Air Conditioning System

Technical values







Technical data for air-conditioning system

Refrigerant distribution in circuit approx.cm3
Compressor 50
Condenser (2 x 20 cm3) 40
Evaporator 30
Fluids with containers 30
Circulating oil quantity in the refrigerant circuit 60


INFORMATION:
- When installing the refrigerant lines, the screw connections must always be wet with refrigerant oil.
- The extracted refrigerant oil must be disposed of as special-category waste.
