Heater and Air Conditioning and Radio Control Module Replacement

Fig 1: Identifying Radio Front Speaker Grille Assembly

Courtesy of SAAB-SCANIA OF AMERICA, INC.

Callout	Component Name
Preliminary Procedure Remove front floor console rear air outlet deflector housing. Refer to FRONT FLOOR CONSOLE REAR COVER REPLACEMENT .
1	Heater and Air Conditioning and Radio Control Module Fastener (Qty: 4) See FASTENER CAUTION .
2	Heater and Air Conditioning and Radio Control Module Procedure After repairs, refer to CONTROL MODULE REFERENCES for programming and set up information.
