Rear Wheel Speed Sensor Replacement

Fig 1: Identifying Rear Wheel Speed Sensor And Mounting Bolt
G09437432Courtesy of SAAB-SCANIA OF AMERICA, INC.
Callout Component Name
Preliminary Procedure
  1. Raise and support the vehicle. Refer to LIFTING AND JACKING THE VEHICLE .
  2. Remove the tire and wheel assembly. Refer to TIRE AND WHEEL REMOVAL AND INSTALLATION .
1 Speed Sensor Bolt
Refer to FASTENER CAUTION .
Tighten
9 Nm (80 lb in)
2 Rear Wheel Speed Sensor Clip (Qty: 4)
3 Rear Wheel Speed Sensor
Procedure
  1. Remove the nut from the wheel shield to get access.
  2. Disconnect the speed sensor electrical connector.
