Installation Procedure

  1. Install the oil pump. Refer to OIL PUMP INSTALLATION .
    Fig 1: Identifying Crankshaft Sprocket
    G09438515Courtesy of SAAB-SCANIA OF AMERICA, INC.
  2. Install the crankshaft sprocket. Refer to CRANKSHAFT SPROCKET INSTALLATION .
  3. Install the primary timing chain. Refer to PRIMARY CAMSHAFT DRIVE CHAIN AND SPROCKETS REPLACEMENT .
