Removal & Installation

  1. Remove outer door panel. See OUTER DOOR PANEL  .
  2. Lower door glass. Remove glass nuts with tool SA9148B. Push glass up and rotate slightly. Remove door glass. See Fig 1 .
  3. To install, reverse removal procedure.
Fig 1: Removing Door Glass
G00133901Courtesy of GENERAL MOTORS CORP.
