Seat Belt Buckle Replacement - Front

Fig 1: Identifying Front Seat Belt Mounting Components

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice in Cautions and Notices. Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .Preliminary Procedure: Remove the front bucket seat. Refer to Seat Replacement - Front Bucket .
1	Handle, Seat Recliner Refer to Seat Back Recliner Handle Replacement - Front .
2	Plug, Seat Recliner Handle
3	Cover, Seat Outer Adjuster Refer to Seat Adjuster Track Cover Replacement - Front .
4	Switch, Power Seat Adjuster Refer to Seat Switch Replacement - Power .
5	Cover, Seat Outer Adjuster Refer to Seat Adjuster Track Cover Replacement - Front .
8	Nut, Seat Belt Buckle Tighten: 53 N.m (39 lb ft)
9	Buckle Assembly, Seat Belt Tip: Disconnect the electrical connector.
