Sedan Model

WARNING: This page is about a different car, the 2005 Subaru Outback and 2005 Subaru Legacy. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the trunk lid trim. < Ref. to TRUNK LID TRIM , REMOVAL, Trunk Room Trim. >
  2. Turn and remove the bulb socket (A).
    Fig 1: Turning And Removing Bulb Socket (Sedan Model)
    G03833567Courtesy of SUBARU OF AMERICA, INC.
  3. Remove the bulb.
