System Specifications

Cylinder Block





Piston





Piston Rings





Connecting Rods





Crankshaft





Main Bearing





Cylinder Block Bolts
Tighten all bolts in the numerical order as shown in the figure.
Tightening torque 12 N-m (1.2 kgf-m, 8.9 ft-lb)





Retighten all bolts 18 N-m (1.8 kgf-m, 13.3 ft-lb)





Tighten all bolts 90°





Install the upper bolt
Tightening torque 25 N-m (2.5 kgf-m, 18 ft-lb)





Crank Pulley Bolt 195 N-m (19.9 kgf-m, 143.8 ft-lb)
