Engine Control System (Diagnostics) - System & Circuit Checks
>>
Starter System (Models Without Smart Entry & Start System)
>>
Circuit figure
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Circuit figure
Fig 1: Clutch Start Switch Assembly - Circuit Diagram
Courtesy of SUBARU OF AMERICA, INC.
