Ignition Lock: Service and Repair

Fig. 6 Ignition lock removal:

1. Disconnect battery ground cable.
2. Turn ignition switch to ``ACC'' position.
3. Insert a small diameter rod into hole located on side of lock cylinder, then while holding down pin, remove lock cylinder, Fig. 6.
4. Reverse procedure to install. Ensure lock cylinder is in ``ACC'' position.
