Feed To Ignitor Test
Turn ignition off. Unplug ignition module 6-pin connector. Ignition module 6-pin module connector is located next to alternator. Turn ignition switch to the ON position. Check for 12 volts between terminal No. 3 and ground on harness side connector. See Fig 1. Reconnect 6-pin connector. If feed voltage is not present, repair open in wiring harness and retest system. If feed circuit is okay, proceed to PICK-UP COIL RESISTANCE.
