Diagnostic Trouble Code Table

WARNING: This page is about a different car, the 2005 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.

HINT:

DTC is displayed on the multi-display (See PRE-CHECK ).

TELEVISION CAMERA ECU (Physical address: 1AC)

HINT:

Fig 1: Diagnostic Trouble Code Table

DIAGNOSTIC REFERENCE

DTC	Diagnosis item	Condition	Countermeasure and inspected parts
40	Camera Picture Error	Synchronous signal from the camera cannot be transmitted.	Check the wire harness between television camera assy and television camera ECU (See DISPLAY SIGNAL CIRCUIT ).
