Circuit Description

WARNING: This page is about a different car, the 2004 Toyota Camry. However, it is still accessible from the selected car via links, so may be relevant.

This sensor detects the temperature and sends the appropriate signals to the A/C amplifier. These signals are used for warm up control when engine is cold.

Fig 1: Identifying Engine Coolant Temperature Communication Circuit Description Table
