Circuit Description
WARNING: This page is about a different car, the 2002 Toyota Prius. However, it is still accessible from the selected car via links, so may be relevant.
A thermistor in the sensor set in a battery pack changes its resistance according to battery temperature. As the battery temperature falls or rises, the resistance rises or falls accordingly.
