Circuit Description
WARNING: This page is about a different car, the 2004 Toyota Camry. However, it is still accessible from the selected car via links, so may be relevant.
A short to the B+ is suspected in the CAN bus line when there is continuity between terminals 16 (BAT) and (CANL) of the DLC3.
