Wireless Door Lock Control System
WARNING: This page is about a different car, the 2003 Toyota Sequoia. However, it is still accessible from the selected car via links, so may be relevant.
This system uses the multiplex communication system, so check diagnosis system of the multiplex communication system before you proceed with troubleshooting.
NOTE:
- Troubleshooting of the wireless door lock control system is based on the premise that the door lock control system operates normally. Accordingly, before troubleshooting the wireless door lock control system, first make certain that the door lock control system operates normally.
- If the trouble still reappears even though there are no abnormalities in any of the other circuits, check and replace the Wireless Door Lock Control Receiver as the last step.
