Section 998 (Fog Light System): Adjustment

WARNING: This page is about a different car, the 2004 Lexus IS 300. However, it is still accessible from the selected car via links, so may be relevant.

ADJUST FRONT FOG LIGHT AIM

A-bolt: Vertical Direction

HINT:

Insert a driver into the hole for aiming in the fender liner to perform aiming.

Fig 1: Adjusting Front Fog Light Aim
G03494231Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
