Back Window Stay ASSY LH: Disposal

HINT:

Use the same procedures for the RH side and LH side.

1. DISPOSE BACK WINDOW STAY ASSY LH
   1. Horizontally fix the stay in a vise with the piston-rod pulled out.
   2. Using a metal saw, gradually cut any area between A and B to release the gas.
      AREA AND MEASUREMENT



      Area	Measurement
      a	80 mm (3.15 in.)
      b	20 mm (0.80 in.)

      CAUTION: As metal debris may be blown outward by the gas, you must:
      • Wear protective glasses.
      • Cover the area being cut.
      NOTE: The gas is colorless, odorless and harmless.
      Fig 1: Identifying Dispose Back Window Stay Assy LH

      Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
