Circuit Description
The idle speed is controlled by the Electric Throttle Control System (ETCS).
ETCS is composed of the throttle motor to operate the throttle valve and the throttle position sensor to detect the opening angle of the throttle valve, the accelerator pedal position sensor to detect the accelerator pedal position, the ECM to control the ETCS, and the one valve type throttle body.
The ECM controls the throttle motor to provide the proper throttle valve opening angle for the target idle speed.
