How To Proceed With Troubleshooting

HINT:

This is a flow chart for vehicle pull.

Fig 1: Suspension System Communication Diagram (1 Of 2)
G04375394Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Suspension System Communication Diagram (2 Of 2)
G04375395Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
