ACCELERATOR PEDAL (for 2WD): Removal

  1. DISCONNECT BATTERY NEGATIVE TERMINAL
  2. REMOVE ACCELERATOR PEDAL ASSEMBLY
    1. Disconnect the accelerator position sensor connector [A].
    2. Remove the 2 bolts [B], then remove the accelerator pedal.
      Fig 1: Removing Accelerator Pedal Assembly
      G04460512Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
