DTC B1795 Occupant Classification ECU Malfunction: Wiring Diagram

Fig 1: Occupant Classification ECU Malfunction - Wiring Diagram
G05236552Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
