Front Wiper Motor: Components

Fig 1: Front Wiper Motor Replacement Components With Torque Specifications
G05236896Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Identifying Front Wiper Motor Components
G05236897Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
