Throttle Body: Components

Fig 1: Camshaft Oil Control Valve Replacement Components With Torque Specifications (1 Of 3)
G05149540Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Camshaft Oil Control Valve Replacement Components With Torque Specifications (2 Of 3)
G05149541Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
