DTC P2009 Intake Manifold Runner Control Circuit Low (Bank 1); DTC P2010 Intake Manifold Runner Control Circuit High (Bank 1): Description
The Intake Manifold Runner Valve (IMRV) motor is driven by the ECM. The IMRV motor opens and closes the IMRV.
When the current of the IMRV motor deviates from the standard range, the ECM determines that there is a malfunction.
The related DTCs are P2004 and P2006 (See DTC P2004 INTAKE MANIFOLD RUNNER CONTROL STUCK OPEN (BANK 1); DTC P2006 INTAKE MANIFOLD RUNNER CONTROL STUCK CLOSED (BANK 1) ), and P2014, P2016 and P2017 (See DTC P2014 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT (BANK 1); DTC P2016 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT LOW (BANK 1); DTC P2017 INTAKE MANIFOLD RUNNER POSITION SENSOR / SWITCH CIRCUIT HIGH (BANK 1) ).
NOTE:
Do not disassemble the IMRV and the IMRV motor.
DTC DETECTION CONDITION CHART
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| P2009 | Detecting open (in the motor or in the motor circuit) Condition (a) and (b) continue for 1 second: (1 trip detection logic)
|
|
| P2010 |
|
|
