DTC C1440/98 Steering Angle Sensor Unusual Bank Angle Detected: Wiring Diagram

Fig 1: Acceleration Sensor - Wiring Diagram
G06003277Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
