Luggage Speaker: Components

Fig 1: Luggage Speaker Replacement Components With Torque Specifications (1 Of 3)
G06035765Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Radio Antenna Cord Replacement Components With Torque Specifications (8 Of 14)
G06036442Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 3: Luggage Speaker Replacement Components With Torque Specifications (3 Of 3)
G06035767Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
