Intake Manifold

INTAKE MANIFOLD






Install the intake manifold and intake manifold stay with the 4 bolts and 2 nuts.
Torque 28 Nm (286 kgf-cm, 21 ft-lbf)


THROTTLE BODY ASSEMBLY





Install the throttle body assembly with the 2 bolts and 2 nuts.
Torque 10 Nm (102 kgf-cm, 7 ft-lbf)
