Fog Light Assembly: Installation

WARNING: This page is about a different car, the 2009 Toyota Prius. However, it is still accessible from the selected car via links, so may be relevant.

HINT:

Use the same procedures for the RH and LH sides.
The procedures listed below are for the LH side.

INSTALL FOG LIGHT UNIT LH
1. Install the fog light bulb to the fog light unit.
2. Attach the 3 claws to install the light unit.
Fig 1: Installing Fog Light Unit LH
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL RADIATOR GRILLE LOWER LH (See REASSEMBLY )
INSTALL FRONT BUMPER COVER (See REASSEMBLY )
INSTALL FRONT FENDER LINER RH (See INSTALLATION )
INSTALL FRONT FENDER LINER LH (See INSTALLATION )
ADJUST FOG LIGHT AIMING (See ADJUSTMENT )
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION
1. Perform initialization (see INITIALIZATION ).
  NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
