Ambient Temperature Sensor: Installation: Installation

WARNING: This page is about a different car, the 2012 Toyota Corolla. However, it is still accessible from the selected car via links, so may be relevant.

INSTALL AMBIENT TEMPERATURE SENSOR
1. Engage the clamp and install the ambient temperature sensor.

  Fig 1: Identifying Ambient Temperature Sensor And Clamp
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
2. Connect the connector.
INSTALL FRONT BUMPER ASSEMBLY (for 2AZ-FE) . Refer to INSTALLATION - Step 1
INSTALL FRONT BUMPER ASSEMBLY (for 2ZR-FE) . Refer to INSTALLATION - Step 2
INSTALL NO. 4 ENGINE UNDER COVER (for 2AZ-FE) . Refer to INSTALLATION - Step 3
INSTALL RADIATOR GRILLE PROTECTOR . Refer to INSTALLATION - Step 4
ADJUST FOG LIGHT AIMING (w/ Fog Light)
Refer to ADJUSTMENT
