Mirror Heater does not Operate with Rear Defogger Switch: Wiring Diagram

WARNING: This page is about a different variant/trim than selected.

Fig 1: Identifying Power Mirror Control System Wiring Diagram

GTY383613

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
