Illustration 2
WARNING: This page is about a different variant/trim than selected.
| *1 | BACK DOOR GLASS COURTESY LIGHT SWITCH | *2 | BACK DOOR LOCK ASSEMBLY |
| *3 | BACK WINDOW LOCK ASSEMBLY | *4 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (for LH) |
| *5 | FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY (for RH) | *6 | FRONT DOOR LOCK WITH MOTOR ASSEMBLY LH |
| *7 | FRONT DOOR LOCK WITH MOTOR ASSEMBLY RH | *8 | GLASS HATCH OPENER SWITCH ASSEMBLY |
| *9 | REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (for LH) | *10 | REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY (for RH) |
| *11 | REAR DOOR LOCK WITH MOTOR ASSEMBLY LH | *12 | REAR DOOR LOCK WITH MOTOR ASSEMBLY RH |
| *13 | G/H NO. 1 RELAY | *14 | DOOR LOCK MOTOR |
| *15 | UNLOCK DETECTION SWITCH | *16 | BACK DOOR COURTESY LIGHT SWITCH |
| *17 | MULTIPLEX NETWORK DOOR ECU | - | - |
