Vehicle Control History [06/2020 - 08/2020]

HINT:

• Vehicle control history (SFI system) is stored when Switch Specification Information learning is incomplete.
• Perform Switch Specification Information after replacing the ECM.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Enter the following menus: Powertrain / Engine / Utility / Vehicle Control History (RoB).

   Powertrain > Engine > Utility

   Tester Display
   Vehicle Control History (RoB)

   HINT:

   It is also possible to display Vehicle Control History during the Health Check, if "Store All Data" isselected.

   VEHICLE CONTROL HISTORY ITEM



   Code	Item	Trigger Description	Stored Group	Reference Inspection Procedure	Link
   X260E	Active Grille Air Shutter Specification Information Learning Incomplete	Switch Specification Information learning is incomplete.	-	Perform Switch Specification Information.	Refer to INITIALIZATION [10/2019 - 08/2020]

   Vehicle Control History Freeze Frame Data

   Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

HINT:

A part of the control history can be confirmed using the vehicle control history.

Refer to VEHICLE CONTROL HISTORY [02/2019 - 08/2020]

HINT:

A part of the control history can be confirmed using the vehicle control history.

for 2WD with NICKEL METAL HYDRIDE BATTERY

Refer to VEHICLE CONTROL HISTORY [11/2018 - 08/2020]

for AWD with NICKEL METAL HYDRIDE BATTERY

Refer to VEHICLE CONTROL HISTORY [02/2019 - ]

for LITHIUM-ION BATTERY

Refer to VEHICLE CONTROL HISTORY [06/2020 - ]
