Components [12/2019 - 10/2022]
Fig 1: Engine Coolant Temperature Sensor Replacement Components [12/2019 - 10/2022]
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Callout
Description
Callout
Description
*1
AIR CLEANER CAP WITH AIR CLEANER HOSE
*2
ENGINE COOLANT TEMPERATURE SENSOR
*3
VACUUM HOSE
*4
NO. 1 FUEL VAPOR FEED HOSE
*5
NO. 2 VENTILATION HOSE
*6
VACUUM HOSE BRACKET
