Miscellaneous Components
MISCELLANEOUS COMPONENTS LOCATION
| Component | Location | |
|---|---|---|
| A/C-Heater Blower Motor Resistors | On A/C-heater housing near blower motor. | |
| Fuse Block | Under dashboard to left of steering column. | |
| Fusible Links | ||
| B, C, D, E, F, G, I, J, L, N, S, T, U, V & W | On right front wheelwell at starter relay. | |
| H | Near marker lights relay. | |
| P | Near trailer lights relay. | |
| Z | At EEC power relay. | |
| In-Line Diodes | ||
| A/C Clutch | In wiring to A/C compressor clutch. | |
| Cargo Light | Above left rear wheelwell in front of cargo light. | |
| Self-Test Connectors | On right front fender apron below starter relay. | |
| Self Test Connector (ABS) | Above the brake pedal, under dash. | |
| Speed Control Amplifier | Behind instrument panel to right of steering column. | |
| Speed Control Servo | On left front wheelwell near brake master cylinder. | |
| Windshield Wiper Interval Governor | Behind left side of dashboard below wiper/washer switch. See Figure. | |
