HFL-Navigation Microphone Removal/Installation
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2014 Honda Ridgeline, 2013 Honda Ridgeline, 2012 Honda Ridgeline, 2011 Honda Ridgeline, and 2010 Honda Ridgeline. However, it is still accessible from the selected car via links, so may be relevant.
- Carefully pry off the lens (A), then remove the mounting screws (B).
- Disconnect the 10P connector (C) from the ambient light (D).
- Remove the ambient light from the housing (E).
- Install the HFL-navigation microphone in the reverse order of removal.
