Component Locations

COMPONENT LOCATIONS

Component Location
Body Control Module (BCM) (1) Behind Instrument Panel, Next To Steering Column
Data Link Connector (DLC) (2) Interior Fuse Panel
LCU01 (1) Driver's Door
LCU02 (1) Front Passenger's Door
LCU03 (1) Right Rear Door
LCU04 (1) Left Rear Door
LCU05 (1) Right Side Of Trunk Compartment
(1) See Fig 1 .
(2) See Figure .
Fig 1: Identifying Body Control Module (BCM) & Local Control Unit (LCU) Locations
G96C06338Courtesy of NISSAN MOTOR CO., U.S.A.
