EX35 Base, AWD
>>
Repair and Diagnosis
>>
Transmission
>>
Automatic Transmission
>>
Function Diagnosis
>>
Shift Mechanism
>>
Cross-Sectional View
>>
2WD Models
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
2WD Models
Fig 1: Cross-Sectional View Of Shift Mechanism - 2WD Models
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
