Rear Speed Sensor: Installation

WARNING: This page is about a different car, the 2008 Toyota Tundra. However, it is still accessible from the selected car via links, so may be relevant.

INSTALL SKID CONTROL SENSOR WIRE
1. Install the sensor clamp with the nut (labeled A).
  Torque: 13 N*m (127 kgf*cm, 9 ft.*lbf)

  NOTE: Make sure the clamp's rotation stopper touches the installation position.
2. Install the sensor clamp with the bolt (labeled B).
  Torque: 13 N*m (127 kgf*cm, 9 ft.*lbf)

  NOTE: When installing the clamp, do not twist the wire harness.
3. Attach the 7 clips (labeled C).
  NOTE:
  - When installing the clamps, do not twist the wire harness.
  - When installing the clamps, securely insert them as shown below.
4. Connect the sensor connector (labeled D).
  NOTE: Securely connect the connector.

  Fig 1: Locating Sensor Clamp With Nut
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL REAR SPEED SENSOR LH
1. Install the speed sensor (labeled A) with the nut (labeled B).
  Torque: 11 N*m (107 kgf*cm, 8 ft.*lbf)
2. Connect the speed sensor connector (labeled C).
  NOTE: Securely connect the connector.

  Fig 2: Locating Rear Speed Sensor With Nut (LH)
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL REAR SPEED SENSOR RH
1. Install the speed sensor (labeled A) with the nut (labeled B).
  Torque: 11 N*m (107 kgf*cm, 8 ft.*lbf)
2. Connect the speed sensor connector (labeled C).
  NOTE: Securely connect the connector.

  Fig 3: Locating Rear Speed Sensor With Nut (RH)
  Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
INSTALL REAR WHEEL
Torque: for Aluminum Wheel

131 N*m (1336 kgf*cm, 97 ft.*lbf)

for Steel Wheel

209 N*m (2131 kgf*cm, 154 ft.*lbf)
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
NOTE: Some systems need to be initialized after the cable is reconnected (see INITIALIZATION ).
CHECK SPEED SENSOR SIGNAL
1. Check the speed sensor signal (see TEST MODE PROCEDURE ).
