Removal and Installation: Removal

  1. Remove instrument lower cover. Refer to "Exploded View ".
  2. Remove glove box assembly. Refer to "Exploded View ".
  3. Remove instrument lower panel RH. Refer to "Exploded View ".
  4. Remove power steering control unit screws.
  5. Remove power steering control unit (1).
  6. Disconnect power steering control unit connector.
    Fig 1: Identifying Power Steering Control Unit
    G05208070Courtesy of NISSAN MOTOR CO., U.S.A.
