TRUNK OPEN FUNCTION : Component Parts Location

Fig 1: Identifying Trunk Open Function Component Parts Location (1 Of 2)
G05970264Courtesy of NISSAN MOTOR CO., U.S.A.
Fig 2: Identifying Trunk Open Function Component Parts Location (2 Of 2)
G05970265Courtesy of NISSAN MOTOR CO., U.S.A.
