Driver Side Power Window does not Operate with Power Window Master Switch: Wiring Diagram

WARNING: This page is about a different car, the 2008 Toyota Tundra. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Power Window Regulator Master Switch Assembly LH Wiring Diagram
G05161433Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
