Removal and Installation: Removal

WARNING: This page is about a different car, the 2011 Nissan Juke. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the NATS antenna amp. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove the push-button ignition switch.
    1. Disengage the push-button ignition switch (1) fixing pawls using minus driver etc.
    2. Press the push-button ignition switch to remove it from cluster lid A (2).
      Fig 1: Removing Push-Button Ignition Switch
      G06936242Courtesy of NISSAN MOTOR CO., U.S.A.
