Component Parts Location
WARNING:
This page is about a different car, the 2008 Infiniti M45 and 2008 Infiniti M35. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Rear View Monitor System Component Parts Location
Courtesy of NISSAN MOTOR CO., U.S.A.
