AV COMM Diagnosis
WARNING: This page is about a different car, the 2013 Infiniti M56 and 2013 Infiniti M37. However, it is still accessible from the selected car via links, so may be relevant.
- Displays the communication status between AV control unit (master unit) and each unit.
- The error counter displays "OK" if any malfunction was not detected in the past and displays "0" if a malfunction is detected. It increases by 1 if the condition is normal at the next ignition switch ON cycle. The upper limit of the counter is 39.
- The error counter is erased if "Reset" is pressed.
| Items | Status (Current) | Counter (Past) |
|---|---|---|
| C Tx(ITM-PrimarySW) | OK/??? | OK/0 - 39 |
| C Rx(PrimarySW-ITM) | OK/??? | OK/0 - 39 |
| C Rx(Amp-ITM) | OK/??? | OK/0 - 39 |
| C Rx(Amp-Audio) | OK/??? | OK/0 - 39 |
|
NOTE:
"???" indicates UNKWN
|
||
