Plug In Indicator Lamp
WARNING: This page is about a different car, the 2011 Nissan Leaf. However, it is still accessible from the selected car via links, so may be relevant.
The plug in indicator lamp turns ON when a charge connector is connected to the normal charge port or the quick charge port. VCM supplies power to the plug in indicator lamp in the combination meter to turn on the lamp when VCM receives the EVSE connecting signal or the quick charger connecting signal from on-board charger.
The plug in indicator lamp operates as per the following.
PLUG IN INDICATOR LAMP CONDITION CHART
| Condition | Illumination status |
|---|---|
| 2 seconds after POWER ON | ON (bulb check) |
| When charge connector is connected | ON |
| Charging | Blink |
| Except above | OFF |
NOTE:
- When the quick charge connector is connected, the indicator lamp is turned ON by turning ON the quick charger start switch.
- When EVSE is connected, the indicator lamp turns ON immediately. The indicator lamp turns OFF after the lapse of 10 seconds with non-operating state.
