CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE FUNCTION: Switch Name and Function

Fig 1: Identifying Conventional (Fixed Speed) Cruise Control Mode Function Switch

Courtesy of NISSAN NORTH AMERICA, INC.

No.	Description	Function
1	CANCEL switch	Deactivates system without erasing set speed
2	RESUME/ACCELERATE switch	Resumes set speed or increases speed incrementally
3	SET/COAST switch	Sets desired cruise speed or reduces speed incrementally
4	MAIN switch	Master switch to activate the system (Press for more than 1.5 seconds)
