Removal and Installation

REMOVAL

Remove front door finisher. Refer to FRONT DOOR FINISHER : Removal and Installation .
Remove power window main switch mounting screws , and then remove power window main switch from front door finisher .

Courtesy of NISSAN NORTH AMERICA, INC.

INSTALLATION

Note the following, and then install in the reverse order of removal.

NOTE:

If power window main switch is replaced or is removed, it is necessary to perform the initialization procedure. Refer to Work Procedure .
The same procedure is also performed for front power window switch (passenger side).
